Serial Number: 00005290

Weight: 8.0 lbs

Condition: Excellent to Mint

Conditional Notes: This guitar is in great condition for 29 years and has experienced very little play wear. No significant marks to be found on the finishes.

-No significant blemishes to note

-Includes original case, documentation, signed COA,

The Peavey Vandenberg Signature guitar is a "made in the USA" super strat type guitar released in 1988. It distinguishes itself from other superstrats by a very unique look. It has a slightly arched top and "fiddle cuts" in the body. The lower cutaway also has an extra scooped cutaway for reaching the highest fret. The scale of the bolt-on neck is 24.75 inch (just like a Les Paul). The headstock is reversed and has a 3 degree tilt and matches the color of the body. The bridge is a Kahler 2700 series licensed under Floyd Rose double locking tremolo. The pickups have an HS configuration with an Alnico bridge humbucker (14.67kOhm) and an Alnico neck single coil (6.47kOhm) with medium/high output both by Peavey. The pickups are both placed at a 2-4 degree angle (parallell with the body's bottom) to eliminate the string spacing problem when Gibson pickups are combined with Fender spaced tremolos.

The Peavey Vandenberg Quilt Top is similar to the Peavey Vandenberg Custom but has a quilted maple top. It has the same set-through construction. A combination  of a set-neck and a neck-through. The neck on this guitar is a mahogany one instead of a maple one though. The guitar has 2 humbuckers instead of an HS configuration. The Pickups were 2 high output custom wound Humbuckers, controls were 2 volume, 2 way switch and an on-on mini switch for coil tapping. Chrome and gold Kahler Spyders came as standard on them too. The Pickups were 2 high output custom wound Humbuckers, controls were 2 volume, 2 way switch and an on-on mini switch for coil tapping. Chrome and gold Kahler Spyders came as standard on them too.

Manufacturer: Peavey

Made in: United States

Series: Peavey Vandenberg LTD

Signature Guitar: Yes

Strings: 6

Construction: Set Neck

Orientation: Right handed

Years: 1990

Body Style: Super Strat

Body Material: Maple Top- Mahogany Back

Body color: Honey Burst

Body finish: Gloss

Top: Yes

Carved top: Yes

Body binding: No

Pickguard: No Pickguard

Nut Width: 41 mm (1-5/8 inch)

12th fret width: 52 mm

Final fret width: 56 mm

Locking nut: Locking Nut

Thickness at nut: 19.00mm

Thickness at 12th fret: 21.00mm

Neck Material: Maple

Neck pieces: 2 Piece

Neck color: Clear

Neck finish: Gloss

Neck binding: Yes

Fretboard: Rosewood

Fretboard radius: 381 mm (15 inch)

Scale Length: 24.75 inch (629 mm)

Frets: 24

Fret Size: Medium

Inlays: Vandenberg Custom

Inlay color: Pearl

Tuning Key Arrangement: 6-in-line

Locking tuners: No Locking Tuners

Headstock color: Matching with body

Headstock finish: Gloss

Headstock angle: angled

Matching headstock: Matching headstock

Tuning Machines: Grover Style

Reversed: Reversed

Bridge brand: Kahler

Bridge type: Floyd Rose type

Hardware color: Gold

Bridge: Kahler Spyder

Neck Pickup Brand: Peavey

Bridge Pickup Brand: Peavey

Piezo: No

Pickup Configuration: HH

Volume knob: 2

3 way switch: 1

Switch: Mini Toggle
